Model Railroad Layouts for Beginners: N Scale and HO Track Plans

For a first layout, N scale (1:160) fits the most track into the least room, and HO (1:87.1, called OO at 1:76.2 in Britain) has the widest choice of models. A 4 x 8 ft board is the classic starting size in both HO and N, according to the NMRA, and a simple oval or a small shelf layout is a sensible first plan. Pick the curve radius your longest locomotive can handle before you pick anything else, draw the plan to scale, and run it as a mock-up before you glue a single piece of track down.

This guide covers the scales, the space each needs, the common plan types, how to check a plan, DC against DCC, and what to buy first. We have not tested any products here; where we mention kit, we say what to check.

📏N, HO and OO: ratio, gauge and size

The scale is the ratio between the model and the real thing. The gauge is the distance between the rails. The NMRA lists N at 1:160, HO at 1:87.1 and OO at 1:76.2. The European standard NEM 010 gives the track gauge for N as 9 mm and for H0 as 16.5 mm, and says British-style 4 mm scale (1:76, gauge 00) is also used. The NMRA track standard S-3.2 has the same targets: 0.355 in (9.0 mm) for N and 0.651 in (16.5 mm) for HO.

Two things are worth knowing. First, OO and HO run on the same 16.5 mm track, but OO trains are bigger, so you cannot mix their models and expect them to look right side by side. By our arithmetic, real standard gauge (4 ft 8 1/2 in, or 1,435 mm, as the NMRA gives it) divided by 76.2 would be about 18.8 mm, so OO's 16.5 mm track is a long-standing compromise. Second, the NMRA says N is "about half" the size of HO and lets scenery "dwarf the trains," while HO is "a better operating scale" for switching. The NMRA also notes that HO has the most products, with N next.

⏱️How much space a starter layout needs

The NMRA says a 4 x 8 ft layout or an 8 x 2 ft modular setup is a good size to start with in HO and N. In metric, 4 x 8 ft is roughly 1.2 x 2.4 m, the size of a sheet of plywood. The same page warns that "you cannot have twice the N scale railroad on a 4x8' as an HO": the track does not simply double, because the curves, not the scale, set what fits.

Curves decide everything. The NMRA layout planning guide gives a rule of thumb: the longest reliable train is about three-quarters of the circumference of a circle with your minimum curve radius. A 27-inch radius gives about ten feet of train. On the same page, a big steam engine does not work on a 20-inch radius in HO.

Here is what that means on a 4 ft wide board, by our arithmetic. A full circle at 27-inch radius is 54 inches across, wider than the 48-inch board. In N, Kato sells starter curves at R315, listed as 12 3/8 inch radius, and tighter R249 at 9 3/4 inch. A full circle at R315 is about 24.75 inches across, so an N oval leaves most of a 4 x 8 ft board for stations, sidings and scenery. The infographic above draws both to scale.

Simple track plans to start with

The NMRA separates continuous-run layouts, where the track turns back on itself, from point-to-point layouts, and notes that layouts around the room's perimeter are usually the most efficient for space.

An oval with a siding or two is the easiest way to learn. A shelf layout, with no loop, suits N or OO in a small room and rewards slow, careful shunting. If you cross the track over itself, remember the NMRA's warning that anything over a 2% grade "will significantly impact the performance of your locomotives and limit train length."

🔎Check the plan before you build

The NMRA's advice is to measure your space first, draw the plan to scale as large as you can, and build a mock-up, because freehand plans "overestimate how much track fits." Before you buy track, run through this list:

• [ ] Space measured, including door swings and where you can stand
• [ ] Minimum radius chosen for your longest locomotive or coach
• [ ] Turnout (point) sizes chosen: the NMRA says a small No. 4 saves space in yards, a larger No. 6 suits mainlines and long rolling stock
• [ ] Sidings and passing loops at least as long as your longest train
• [ ] Reverse curves (S-curves) separated by straight track longer than your longest vehicle
• [ ] Grades at 2% or less, with easy transitions at top and bottom
• [ ] Clearances to buildings and neighbouring tracks checked with a gauge (NMRA RP-7)
• [ ] Aisle of at least 24 inches for one person, 36 inches if two people will operate

Planning software can help you check this. The NMRA lists SCARM, Templot, Anyrail, Atlas and 3rdplanit, and it names books such as Mindheim's How To Design A Small Switching Layout (2009). Magazines, books and online layout plans are all sources of published plans; it is best to start with one and change it to suit your room. Check each program's licence and limits before relying on it.

Baseboard basics

The NMRA benchwork guide suggests an open grid built from 1 x 4 inch boards with stringers every 16 to 24 inches, topped with plywood in the 5/8 to 3/4 inch range (about 16 to 19 mm) or 2 inch foam insulation board. It says a bench height between 38 and 52 inches is comfortable for most modellers, and some people use a hollow-core interior door as a deck. Put an access hatch in anywhere you cannot reach. Sawing and sanding make dust, so see our woodworking workshop dust guide for ventilation and masks.

DC or DCC

The NMRA explains the difference. In DC (analog) the track power goes straight to the motor, and you split the track into blocks to run more than one train. In DCC (Digital Command Control) the track carries power plus commands, and a decoder in each locomotive reads its own; many trains can share the same track under independent control, and sound is possible. DCC wiring uses heavy bus wires (14 AWG or larger) with 18 AWG feeders, and the NMRA says not to use common-rail wiring with DCC. It does not compare prices, so check what the locomotives you want are fitted with, and whether a decoder is included or sold separately.

🛒What to buy first

The NMRA recommends starting small and being willing to throw away early layouts, using sectional or flexible track, easy-to-build plastic structures, and a decent power pack ("cheap power packs do not perform well"). It also says to test-run any locomotive before you buy. A sensible shopping order is:

1. Track, turnouts and a controller in one scale and one rail type
2. One reliable locomotive and a few wagons or coaches
3. Baseboard materials
4. Scenery and buildings, once the trains run well

Many beginners start with a boxed train set. If you are buying for a child, our guide to craft kits and hobby boxes for kids covers age fit and skill.

What to buy, if anything

Free material covers a lot: the NMRA's beginner series is free to read, and published plans appear in magazines and books. An e-book such as a "Beginners Guide to Model Railroading" can still help if you want everything in one place: it can gather the basics, explain the vocabulary and give a build order. It cannot replace measuring your own room, checking your locomotives' minimum radius, or testing a plan with a mock-up. We have not tested it. Before paying, look for what is in the contents list, whether the track plans are drawn to scale and say which scale, whether the advice covers both DC and DCC, and what the refund terms are.
